EFFILUX, the innovative provider of LED lighting solutions for machine vision, was recognized among the best in the industry by the judges of the Vision Systems Design 2020 Innovators Awards program for its VIS-NIR hyperspectral LED lighting series, the EFFI-FLEX-HSI, a joint effort between EFFILUX (Paris, France) and mother company CCS Inc. (Kyoto, Japan). The proprietary wideband single LED solution has a tunable continuous spectrum from 400 nm to 900 nm which is ideal for hyperspectral imaging applications. This light-source maximizes the benefits of LED technology for hyperspectral imaging without the limitations of using halogen or multiple narrow-band LED solutions and can be built into a wide range of illuminators by the CCS Group, including projectors, bar, ring, and back lights. “The Vision Systems Design team would like to congratulate CCS and EFFILUX for being publicly recognized by the esteemed judging panel of the 2020 Innovators Awards program,” says John Lewis, Editor in Chief. “Each year this unbiased and increasingly competitive program aims to celebrate the most innovative products and systems in machine vision, and both teams should be very proud of their accomplishment.” CCS and EFFILUX will continue to actively utilizing the technical capabilities of both companies to offer innovative solutions and help customers illuminate what needs to be visible. For more information, please do not hesitate to contact us at sales@effilux.fr. |
![]() |
Reveal the invisible with Effilux PureUV™ Technology |
Fluorescence is the property of some materials to emit light under UV radiation. The radiation is absorbed at a specific wavelength (eg. UV 365nm) and then re-emitted at a longer wavelength (eg. Blue). This phenomenon reveals glue, ink, coatings or any materials with UV optical brighteners. Typical application: Detection & inspection of fluorescent printing, polymers, dyes on various objects such as packaging, security strip, glass, etc. |
Go beyond the limit of conventional UV imaging with EFFILUX PureUV™ technology: |
|
![]() |
Common Problem 1:
PureUV™ Technology: |
Common Problem 2:
PureUV™ Technology: |
![]() |
![]() |
Common Problem 3:
PureUV™ Technology: |
|
Effilux also offers a wide range of UV lights in various wavelengths (365nm, 385nm, 395nm, 405nm) and form factors (bar, ring, line, projector), to meet different usage requirements of your machine vision applications. |
|
Accessories |
|
![]() FiltersUV Cut filters: LP415 / BP470 / BN470 |
![]() Protective glassesRecommanded for UV applications. |
|
![]() |
![]() |
Having difficulty finding the perfect & stable contrast for your applications? |
Lighting plays a very important role for machine vision imaging. The right lighting creates the perfect light-dark contrast and makes the important details visible. Which wavelength: UV, Visible, IR, etc? Which form factor: Backlight, Direct, Coaxial, etc? Which camera filters: Band-pass, Long-pass, Linear polarizer, etc? And the list goes on. EFFILUX offers convenient services to help you overcome your imaging challenges. |
|
Click here to find out more |
![]() |
![]() |
Introducing the new EFFILUX HSI hyperspectral lighting series - Industry-first hyperspectral lighting solution created from a single proprietary LED developed by CCS Inc. |
Benefits at a glance |
![]() |
• Single broadband LED design for relatively flat spectrum between 400nm and 900nm • Using a single chip to create a broadband spectrum allows exceptionally high spectral uniformity across the illuminated area • Strobe function for high power applications, camera synchronization, and longer lifetime • Excellent spatial & spectral uniformity without wavelength-dependent angular absorption effects • Available in the most common form factors required for machine vision and scientific imaging • Easy integration into wide range of light types, area & line scan, to fit different hyperspectral imaging application requirements |
|
Hyperspectral illumination technologies comparison |
||||||||||||||||||||||||||||||||
|
|
![]() EFFI-Flex-HSIHyperspectral Visible-NIR LED bar light. |
![]() EFFI-BL-HSIHyperspectral Visible-NIR LED backlight. |
![]() EFFI-Sharp-HSIHyperspectral Visible-NIR LED projector. |
|
Ideal for Many Applications |
Optical sorting and quality control systems, biotech and microscopy systems, security and counterfeit detection, waste sorting and recycling, medical imaging and diagnostics, and many others. |
|
Contact us now or click here to find out more about our comprehensive range of hyperspectral solutions. (Hyperspectral standard range, custom solutions for larger spectrum, multispectral SWIR, ...) |
![]() |
EFFILUX is excited to exhibit at the Measurement World 2019 in Paris Expo Porte de Versailles, from September 24th - 26th 2019. Come visit us at our booth C34 to see our latest innovations and discuss how we can help you achieve the solution you need! |
Hyperspectral - New optimized hyperspectral spectrum |
||
![]() |
With our combined expertise in optics & LEDs and a close collaboration with hyperspectral camera manufacturers, Effilux proposes the best solution to fit any specific need. |
SWIR – New powerful SWIR product range & award-wining projector |
||
![]() |
The innovative high-power LED SWIR source which was developed by Effilux can be well adapted to different cameras, taking your machine vision inspection to the next level. |
Backlight – Thin, Robust & Waterproof backlight rated IP67 |
||
![]() |
Our new thin styled backlight comes with excellent uniformity, an integrated or cable type controller, and is available in any size & color to overcome challenging inspection environments. |
- Join the conference on Hyperspectral, SWIR & 3D technologies with our sales manager, Arnaud Mestivier, on September 24th – 3:30 pm |
|
Please do not hesitate to contact us for more information or get your invitation. |
![]() |
The comprehensive backlight range that meets every special need of machine vision applications
|
![]() |
Optical Flexibility |
||
![]() |
• Excellent uniformity (>90%). • Anti-reflection system to absorb unwanted reflections from interfering light. • Available in White and Monochromatic (Blue, Green, Red, IR, SWIR). |
|
- Optical accessories - |
||
![]() |
![]() |
![]() |
PolarizerTo highlight solder, hole, or difference in thickness in transparent materials |
Cylindrical lensTo improve collimation and increase luminance |
Zebra maskFor deflectometry applications |
Collimator filter: To improve the contour’s definition of the object detected through vision system. Available upon request. |
Electrical Flexibility |
|||
![]() Standard version |
![]() Power version ("S150")* |
![]() High power version ("S600")* |
|
*: Only for strobe applications. |
Mechanical Flexibility |
|
![]() Standard versionEFFI-BLFrom 50mm x50mm to every |
![]() Thin Edge versionThin edges EFFI-BLFrom 50mm x50mm to every |
![]() IP67 Thin edge versionEFFI-BL-IP67From 100mm x100mm to every |
![]() IP69K stainless steel versionEFFI-BL-IP69KFrom 100mm x100mm to every |
![]() IP67 Thin edge compact versionEFFI-SBLFrom 25mm x25mm to every 25mm increment, 15mm thickness |
![]() IP69K Thin edge compact versionEFFI-SBL-IP69KFrom 25mm x25mm to every 25mm increment, 15mm thickness |
![]() Linescan versionEFFI-Flex-BLFrom 100mm to every |
![]() Customize versionDimension, Shape, Thin Edge, Attachment, |
Easy-to-use fasteners are also available. |
|
Please visit our website or contact us to find out more. |
|
![]() |
|
![]() |
![]() |
![]() |
![]() A big thank you to our valued customers and partners. Your success and satisfaction have always been the biggest drivers for us to create innovative products & technologies and deliver the most suitable solutions. Yours Sincerely, |
![]() |
Some figures in 10 years:![]() |
![]() |
|
Big size dome light (500mm) now available at EFFILUX : |
![]() |
>> Inspection’s area up to 500mm >> Available with Auto-Strobe or dimmable electronics >> Monochromatic or multispectral (RGB, WUI, …) >> Compatible with standard EFFILUX fasteners |
Discover it in detail on the product page. |
|
|
![]() |
Das EFFILUX Team ist zurück von der VISION 2018. Es war ein voller Erfolg! Wir bedanken uns recht herzlich für die vielen Besuche auf unserem Stand und freuen uns Sie in zwei Jahren wieder begrüßen zu dürfen. |
![]() |
EIN KURZER ÜBERBLICK UNSERER NEUEN PRODUKTE AN UNSEREM MESSESTAND |
![]() |
Große High-Power Dombeleuchtung. |
Kompakte Bauweise für beengten Bauraum. |
![]() |
![]() |
Unsere neue Multispektrale LED Beleuchtung. |
Eine neue Produktlinie für SWIR Anwendungen. |
![]() |
Wir freuen uns auf Ihre Projekte! |
|
EFFILUX is launching its new compact range. These new products have been designing to be easily integrated in constrained areas and still guarantee more power, consistency and flexibility. |
![]() |
>> Thickness >> Flexible products >> Photometric stereo |
Visit us at booth 1 H 65 to discover this new range |
|
Between visible and thermal imaging, the SWIR (Short Wave InfraRed) is particularly interesting but until now, these applications were limited by the lightings ‘power. |
EFFILUX is proud to present its new range of powerful SWIR LED lightings |
![]() |
>> Full range of products >> Powerful lightings for machine-vision applications >> High adaptability with all SWIR cameras |
![]() |
Visit us on booth 1 H 65 to discover concrete applications ! |
Besuchen Sie uns auf der VISION 2018 in Stuttgart, Halle 1 Stand 1H65.
Wir freuen uns darauf, mit Ihnen zusammen über die neuesten Produkte und Innovationen zu sprechen!
Contact us to get your free ticket.
|
Hyperspectral imaging represents a new trend in machine vision industry. EFFILUX integrates innovative technologies in order to answer to these new requests from the market. Full spectrum from 400 to 1000 nm or multi spectral from UV to SWIR, EFFILUX is able to propose most advanced technologies to meet customer’s request. |
![]() |
>> Customizable spectrum (from 400nm to 1700nm) >> LED technology brings robustness and stability >> industrial integration |
![]() |
SWIR (Short Wave InfraRed): |
Most of lightings used in machine vision applications do not allow the detection of certain liquids and / or materials.
Thanks to "near infrared" lighting (SWIR), it is now possible to reveal these elements.
Indeed, this spectral range allows to :
>> See through some materials / objects ( ex : wafer, plastics, organical, ... )
>> See through smoke
>> Detect the presence of water / liquid
EXAMPLES OF COMMON CONSUMPTION PRODUCTS
Highlighting of liquid level
through a barrel
Mise en évidence de l'accumulation d'eau
dans une pomme.
EFFILUX offers innovative technology for producing SWIR lighting from 900 to 1500 nm (Multi Band or Wide Spectrum).
EFFILUX Optical knowledge for a better contrast |
In addition to an efficient LED lighting, an innovative EFFILUX technology allows you to eliminate unwanted reflections. |
Results WITHOUT EFFILUX technology
Results WITH EFFILUX technology
>> No specular reflection on the inspected object. >> Better contrast. >> Wide range of lightings (365 to 405nm). If you are inerested in this type of application : Please contact us |
Designed for high-speed video |
Optimized for short range working distances (5 to 50 cm), the EFFI-SPOT is perfectly suited for short exposure time applications. With this lighting system, it is possible to control light intensity (dimming control) while avoiding flicker effect (flicker-free). |
>> Its high compactness, power and integrated fan make it the ideal projector for industrial and scientific high-speed applications. ![]() More information |
EFFILUX will be present at the UKIVA Exhibition (UK Industrial Vision Association) that will take place at Milton Keynes in the United-Kingdom on April 27th 2017. This new conference & exhibition of machine vision will allow you discover the latest developments in the world of industrial imaging. |
>> Do not hesitate to come visit and attend to our conference: STAND n°53 ! More information |
Specially designed for machine vision applications in food industry & harsh environments. |
>> 100% Waterproof stainless steel (IP69K) >> FDA compliant See range |
3D RECONSTRUCTION, STEREOVISION and ALIGNEMENT APPLICATIONS |
>> 6 to 15 times more powerful than its predecessors. >> Easily interchange masks. See range |
EFFILUX was present at the VISION SHOW 2016 (International Exhibition of Machine Vision in Stuttgart).
We thank all our visitors for contributing to the success of this show and hope to see you there in 2018 !
The video of the new LED bar EFFI -Smart is now online!
AUTOMATICA in Munich is on! You can now join EFFILUX on booth B5.507B from 21 to 24 June.
UWAVE, subsidiary of EFFILUX specializing in UV LED sources, is present at DRUPA show in Düsseldorf on stand 6B09 until June 10! The opportunity to expose ULINE, the unique system reaching 14W/cm² at 365 nm and 16W/cm² at 385 and 395 nm. EFFILUX is also on site, we would be happy to welcome you!
EFFILUX will exhibit its range of innovative LED lightings for machine vision. You will discover its new products 2016, including EFFI-Smart, EFFI-Lase V2 and EFFI-Sharp V2. See you on the stand B5.507B from June 21 to 24 at AUTOMATICA in Munich !
EFFI-Smart is a double row high power LED bar available in many wavelengths and in 3 configurations (2 rows of 3, 12 or 36 LED). This is the most powerful solution of EFFILUX (2 times more powerful than the previous LED bar EFFI-Flex).
Providing IP65 sealing, the product is customizable by the client. He can open it to change the position of the lens (4 positions) and the window (transparent, semi-diffuse and opaline). Therefore, the client controls both the emission angle and the homogeneity/power.
EFFI-Smart is in some ways the assembly of tricks and technologies of EFFILUX in one product :
Main characteristics :
- Available wavelengths : green, blue, red, IR et white
- Aluminium housing
- Waterproof IP 65
- Flexible
- Adjustable emission angle
- Chainable: Double I/O connectors
- Auto strobe PNP or NPN and analogic DIM
- Many optical accessories (polarizer, diffusers)
EFFI-Lase White LED together with Photon Focus camera / AQSENSE to make 3D color inspection of corks.
The award MONTGOLFIER 2016 took place Thursday, March 17, 2016 in the prestigious halls Light and Montgolfier of the Hotel Industry of the Society for the Encouragement of National Industry. During the ceremony, Olivier Mousson, president of the Society for the Encouragement, awarded the highest honors, before an audience of entrepreneurs, researchers, intellectuals , journalists and politicians.
Montgolfier of Physical Arts Committee awarded to Jean-Philippe Blanchot, manager and Arnaud Mestivier, sales manager of EFFILUX.
